MONITOR
• Screen Size (W × H), mm 137.40 × 77.28 (6.2 inch)
• Aspect Ratio : 16:9
• Display Type : Transmission type TN liquid crystal display
• Drive Principle : TFT (thin-film transistor) active matrix display
• Number of Pixels : 1,152,000
• RCA Video Input : 1.0 Vp-p (input impedance 75Ω)
• RCA Audio Input : 130 ± 60mVms (Input impedance 10kΩ or greater)
TUNER SECTION
• Frequency Bands : FM/AM
• FM: (MHz) 0.05 MHz steps : 87.5 - 108.0
• AM: (kHz) 9 kHz steps : 531 - 1,629
DVD SECTION
• Useable Discs : DVD video / DVD ± R/RW
• Frequency Response (Hz) 20 to 20,000(48kHz)(0 ± 3db)
• Distortion (%) 0.05
CD SECTION
• S/N Ratio (dB) 1 kHz 80
• Frequency Response (Hz) 20 to 20,000(48kHz)(0 ± 3db)
• Dynamic Range (dB) 1 kHz : 95dB
• Harmonic Distortion (%) : 0.05%
AUDIO SECTION
• Power Output (DIN45324, +B = 14.4 V) 4 × 19W
GENERAL
• Dimensions (W × H × D), mm 178 × 100 × 163
• Weight (kg) 2.4
• Power Consumption : 4.0A (at 1W)
• Power Requirement : 14.4V DC (10.5 ～ 15.8V)
• Speaker Impedance : 4Ω (4Ω to 8Ω allowable)
